ROADTEC RP-190 HIGHWAY CLASS ASPHALT PAVER
OVERVIEW
THE RP-190 IS A POWERFUL, RUBBER-TIRED PAVER ENGINEERED FOR HIGHWAY WORK.The RP-190 features our exclusive anti-segregation design of the feed tunnel, discharge, and rear augers. The heavy-duty frame, solid front axle, and sturdy conveyors are engineered for durability. Seats of the dual operator stations can move hydraulically out beyond the sides of the machine to give the operator an excellent view down the sides of the machine. The four-way adjustable operator seats feature a ride control tension system for ultimate comfort.

SPECIFICATIONS
Engine SpecificationsEngine MFG CumminsModel QSB 6.7Max Power 230 hp @ 1,900 rpmNumber of Cylinders 6Electrical 24

Weight & Dimensions Specifications
Shipping Length (Tractor Only) 17' 7Shipping Length with Rear Mount Screed 22' 7'Shipping Width 10' 6Shipping Height 10' 3/4Tractor Operating Width 10' 6Deck Height 6' 2Wheelbase 9' 2Inside Turning Radius 11' 3Weight (Tractor Only) 36,700 lbs

Capacities Specifications
Hydraulic Tank Capacity 76 galFuel Tank Capacity 100 galCooling System 9 galDEF 5 gal

Drive Specifications
Final Drive 2 speedNumber of Drive Pumps 2Number of Drive Motors 2Paving Speed 0-284 fpmTravel Speed 0-12 mphRear Tire Size 18.00 R25Front Tire Size 14 x 22Ground Clearance 7Steering Steering WheelControls Movement Hydraulic SwingSuspension Rubber TireFront Bogies Balanced

Feed System Specifications
Hopper Capacity 13.8 ton/252 ft3Hopper Width 10' 3Feed Control Sonic and Flow GatesAuger Diameter 16Distance Between Augers and Back Wall 1.5Minimum Auger Height 2Hydraulic Tunnel Extensions Optional
