DYNAPAC CC3200C
Operating Mass: 7700 kg
Static linear load: 23.6 kg/cm
Compaction width: 1730 mm
TECHNICAL DATA+
Masses
Max. operating mass 8500 kg Operating mass (incl. ROPS) 7700 kg Module mass (front/rear) 4075 kg/ 3625 kg

Traction
Speed range (Dual/TC/AS) 0-12 km/h Vertical oscillation ±7 Max. theoretical gradeability 45 %

Compaction
Wheel load 906 kg/wheel Centrifugal force (high/low amplitude) 90/ 75 kN Nominal amplitude (high/low) 0.7/ 0.3 mm Static linear load 23.6 kg/cm Vibration frequency (high/low amplitude) 48/ 67 Hz Water tank 750 l Emulsion tank 78 l

Engine
Manufacturer/Model Deutz TCD 3.6 HT T4f Type Water cooled turbo Diesel Rated power, SAE J1995 55 kW (74 hp ) @ 2200 rpm Fuel tank capacity 130 l Alternative Engine Manufacturer/Model Cummins QSB 3.3 IIIA/T3 Type Water cooled turbo Diesel Rated power, SAE J1995 74 kW (99 hp) @ 2200 rpm Alternative Engine Manufacturer/Model Deutz TCD 3.6 HT StageV Type Water cooled turbo Diesel Rated power, SAE J1995 55 kW(74 hp) @ 2200 rpm

Hydraulic system
Driving Axial piston pump with variable displacement. Axial piston motors (3) with variable displacement. Vibration Axial piston pump with variable displacement. Axial piston motor with constant displacement. Steering Gear pump with constant displacem. Service brake Hydrostatic in forward and reverse lever. Parking/ Emergency brake Failsafe multidisc brake in both drums.

OPERATIONS & MAINTENANCE MANUALS+
FLUIDS+
COOLANT - NO CAB Type of fluid Volume Additional info Dynapac Coolant 100 18,6 l for Cummins 18,9 l for Deutz P/N 25 l can 4812161854

COOLANT - WITH CAB
Type of fluid Volume Additional info Dynapac Coolant 100 20,1 l for Cummins 20,1 l for Deutz P/N 25 l can 4812161854

DRUM GEAR
Type of fluid Volume Additional info Dynapac Gear Oil 300 1,7 l P/N 5 l can 4812161883 20 l can 4812161884 209 l drum 4812161885

DRUM OIL
Type of fluid Volume Additional info Dynapac Drum Oil 1000 9 l P/N 5 l can 4812161887 20 l can 4812161888 209 l drum 4812161889

ENGINE
Type of fluid Volume Additional info Dynapac Engine Oil 200 7 l for Cummins engine P/N 5 l can 4812161855 20 l can 4812161856 209 l drum 4812161857

GREASE
Type of fluid Volume Additional info Dynapac Roller Grease - P/N 0.4 kgs cartridge 4812030096

HYDRAULIC OIL TANK
Type of fluid Volume Additional info Dynapac Hydraulic 300 40 l P/N 5 l can 4812161867 20 l can 4812161868 209 l drum 4812161869

WHEEL GEAR
Type of fluid Volume Additional info Dynapac Gear Oil 300 0,8(x2) l P/N 5 l can 4812161883 20 l can 4812161884 209 l drum 4812161885

SERVICE KITS+
BACK UP ALARM KIT Category Subcategory P/N Additional info Compaction Combi rollers 470PP81168 CHIP SPREADER. DRIVING LIGHTS KIT Category Subcategory P/N Additional info Compaction Combi rollers 470PP81144 ECCENTRIC SHAFT KIT Category Subcategory P/N Additional info Compaction Combi rollers 4700945722 EDGE PRESS, JOINT CUTTER DISC Category Subcategory P/N Additional info Compaction Combi rollers 470PP81099 EDGE PRESS DEVICE, JOINT CUTTER DISC, 80 MM 3.1 INCH Compaction Combi rollers 470PP81129 EDGE PRESS, FRONT RIGHT MOUNTED SCRAPER KIT Category Subcategory P/N Additional info Compaction Combi rollers 4700945908 SERVICE KIT , 1000H Category Subcategory P/N Additional info Compaction Combi rollers 4812159383 (IIIB/T4i) No. Oil SERVICE KIT , 500H Category Subcategory P/N Additional info Compaction Combi rollers 4812159381 (IIIB/T4i) No. Oil Compaction Combi rollers 4812159382 (IIIB/T4i) Inc. Oil SERVICE KIT , 50H Category Subcategory P/N Additional info Compaction Combi rollers 4812159352 (IIIB/T4i) Inc. Oil SHOCK ABSORBER KIT Category Subcategory P/N Additional info Compaction Combi rollers 4812156382 Split Drum SPRINKLER KIT Category Subcategory P/N Additional info Compaction Combi rollers 4812155698 WORKING LIGHTS KIT Category Subcategory P/N Additional info Compaction Combi rollers 470PP81096 COMPACTION DATA+ SCHEMATICS+ Eager to see the schematics of Dynapac CC3200C? Please Log in or Register to MyDynapac to get access.
