VOLVO ECR18E
The ECR18E is a 1.8 tonne class machine that can squeeze into the tightest of spaces, and thanks to its ultra-short tail design –. Easy to transport and easy to operate, this 1.8t excavator will make light work of tough jobs. With a robust design, combined with best-in-class service access, you can be sure this is a machine designed to promote low operating costs. The ultra-short swing radius ECR18E is the perfect choice for working in tight conditions. Easy to transport and easy to operate, this 1.8t excavator will make light work of tough jobs. With a robust design, combined with best-in-class service access, you can be sure this is a machine designed to promote low operating costs.
TECHNICAL SPECIFICATIONS FOR ECR18E
Here are the key specifications for this product model.
METRIC IMPERIAL
Engine Volvo D0.9A Gross power 12 kW Net power 11.8 kW ...at engine speed 2,300 rpm Operating weight 1,700 kg Operating weight, canopy version 1,700 kg Bucket capacity 0.01 - 0.05 m³ Travel speed, low / high 1.8 / 3.5 km/h Slewing speed 9.5 rpm Breakout force 12.9 kN Tear out force (arm breakout force) 8 kN Overall width 995 - 0 mm Overall length 3,431 mm Main hydraulic pump max. flow 34 l/min
SHORT SWING, BIG PERFORMANCE
The ECR18E is a 1.8 tonne class machine that can squeeze into the tightest of spaces, and thanks to its ultra-short tail design – the shortest radius in the Volvo range – it can work close to obstacles without colliding with them.
SMALL BUT TOUGH
The unique high-profile counterweight design is made from three strong pieces of cast iron which wrap around the rear of the machine, protecting all vital components. All-round steel panels, recessed 10mm from the counterweight, offer further protection.
SAFE AND EASY OPERATION
The roomy and uncluttered operator environment of the machine is designed to keep you safe and focused while at work, including simple layout of the controls, fingertip control and large travels pedals. Safety is built-in to the machine with a ROPS/TOPS/FOPS canopy, a large entrance including high visibility step, and an orange seatbelt as standard for easy checks by site managers.
BEST-IN-CLASS SERVICEABILITY
Complete maintenance tasks with speed thanks to the hinged fuel tank which enables an impressive ease of access to the engine compartment, and easy to locate daily check points. A 50-hour greasing interval further contributes towards the best-in-class serviceability of this machine.
TRANSPORT WITH EASE
Transportation of the machine is safe and secure, thanks to its light weight and convenient design. With automatic slew lock and four easily accessed large tie-down points on the upper frame, the machine can be safely transported on a small trailer with up to three buckets and a hydraulic breaker, while maintaining a total transport weight of less than 2t.
