Create parametric symbols for Smart 3D – no programming skills needed
3D SymbolDesigner reduces the man hours needed to create parametric symbols for Smart 3D by up to 80 percent. It comes with an easy to use graphical user interface for the creation and documentation of parametric symbols.

Simple to use
Create parametric symbols for equipment, piping and support parts. No programming knowledge required.

Automated creation
3D SymbolDesigner automatically produces the Visual Basic project (Visual Basic 6, Visual Basic .NET) and Microsoft Excel bulkload sheet templates.

Includes documentation
3D SymbolDesigner automatically publishes a datasheet for each symbol when the symbols are produced.
