HB365LC-3
Horsepower 269 HP @ 1,950 rpm
Operating weight 81,791 - 85,495 lbs.
Bucket capacity 0.89 - 2.56 yd³
Specifications for HB365LC-3
Engine
Model Komatsu SAA6D114E-6* Type Water-cooled, 4-cycle, direct injection Aspiration Turbocharged, aftercooled, cooled EGR Number of cylinders 6 Bore 4.49 in Stroke 5.69 in Piston displacement 540 in³ Horsepower: SAE J1995 / Gross 271 HP ISO 9249/SAE J1349 / Net 269 HP Fan at maximum speed / Net 251 HP Rated rpm 1,950 Fan drive method for radiator cooling Mechanical with viscous fan clutch Governor All-speed control, electronic. *EPA Tier 4 Final emissions certified
Hydraulics
Type: HydrauMind (Hydraulic Mechanical Intelligence) system, closed-center system with load sensing valves and pressure compensated valves
Number of selectable working modes 6
Main pump: Type Variable displacement piston type Pumps for Boom, arm, bucket, swing, and travel circuits Maximum flow 141.3 gpm Supply for control circuit Self-reducing valve Hydraulic motors: Travel 2 x axial piston motors with parking brake Swing 1 x axial piston motor with swing holding brake Relief valve setting: Implement circuits 5,540 psi Travel circuit 5,540 psi Pilot circuit 470 psi Hydraulic cylinders / Number of cylinders: Bore x Stroke x Rod Diameter Boom / 2 5.5 x 58.3 x 3.9 in Arm / 1 6.3 x 71.9 x 4.3 in Bucket for 10 ft. 5 in and 13 ft. 2 in Arms / 1 5.5 x 50.6 x 3.9 in Drives and Brakes Steering control Two levers with pedals Drive method Fully hydrostatic Maximum drawbar pull 65,191 lbs. Gradeability 70%, 35° Maximum travel speed: (Auto-Shift) High 3.4 mph Mid 2.8 mph Low 2.0 mph Service brake Hydraulic lock Parking brake Mechanical disc brake Swing System Drive method Electric drive Swing reduction Planetary gear Swing circle lubrication Grease-bathed Service brake Electric brake Holding brake / Swing lock Mechanical disc brake Swing speed 9.5 rpm Swing torque 82,313 ft.-lbs. Undercarriage Center frame X-frame Track frame Box-section Track type Seale Track adjuster Hydraulic Number of shoes 48 each side Number of carrier rollers 2 each side Number of track rollers 8 each side Coolant & Lubricant Capacity (Refilling) Fuel tank 159.8 US gal Coolant (Engine) 11.1 US gal Ultra capacitor cooling system 3 US gal Engine 10.2 US gal Final drive, each side 2.4 US gal Swing drive 4.12 US gal Swing motor - generator 0.95 US gal Motor-generator 2.25 US gal Hydraulic tank 49.7 US gal DEF tank 10.3 US gal Sound Performance Exterior ISO 6395 101 dB(A) Operator ISO 6396 69 dB(A)
Operating Weight (Approximate)
Operating weight including 21 ft. 3 in one-piece HD boom, 10 ft. 5 in arm, 33.5 in track shoes, SAE heaped 2.56 yd3 bucket, rated capacity of lubricants, coolant, full fuel tank, operator, and standard equipment.
Triple-Grouser Operating Weight Ground Pressure (ISO 16754)
28 in 83,012 lbs. 8.79 psi 31.5 in 83,894 lbs. 7.77 psi 33.5 in 84,335 lbs. 7.35 psi
