PC240LC-11
Horsepower 177 HP @ 2,000 rpm
Operating weight 55,763 - 56,360 lbs.
Bucket capacity 0.76 - 1.85 yd³
High production earthmoving from an excavator designed to be easily transportable. Quick response and smooth operation to maximize your work. The PC240LC-11 is a mid-size hydraulic excavator designed to offer extended dig depth and reach for most utility applications.
Large high-strength steel castings on the boom, arm and bucket link Closed-center load-sensing hydraulics for precise, fine control Large displacement high-efficiency pumps provide optimal attachment flow Large, spacious, quiet cab featuring standard air suspension seat
Features and benefits
Large displacement high efficiency pump
Large displacement hydraulic implement pumps provide high flow output at lower engine RPM, operation at the most efficient engine speed.
Closed-center load-sensing hydraulic system
Smooth operation, quick cycle times, great multi-function, while lowering fuel consumption from closed-center load-sensing hydraulic system.
Built for strength
Equipment designed for long-term durability with high resistance to bending and torsional stress. Booms and arms are constructed with thick plates of high tensile strength streel and designed with large cross-sectional areas.
Cleaner emissions
A heavy-duty aftertreatment system that combines a Komatsu Diesel Particulate Filter (KDPF) and selective catalytic reduction (SCR). The system injects the correct amount of diesel exhaust fluid at the proper rate, decomposing nitrogen oxide.
Easy access
Engine oil check and filter locations integrated into one side to allow easier maintenance access.
Advanced ergonomic design
Wide spacious cab includes a heated air suspension seat with reclining backrest. Seat height and position are easily adjusted using a pull-up lever. Armrest position easily adjusted with the console.
Information at your fingertips
Updated, large, high-resolution LCD color monitor to ease accurate and smooth work. Key machine information displayed in user-friendly interface, rearview camera and DEF level gauge display added to default main screen.
Rollover protection
A ROPS cab that conforms to ISO 12117-2 comes as standard equipment. It also satisfies requirements for level 1 operator protective guard (OPG) and top guard (ISO 10262).
Multi-operator productivity
An operator identification ID can be set up for each operator and used to manage operation information of individual machines using Komtrax data. Data can analyze operation status by operator and by machine.
Reduce fuel consumption
Auto idle shutdown automatically shuts the engine down after idling for a set period to reduce unnecessary fuel consumption and exhaust emissions. Time before engine is shutdown can be programmed from 5 to 60 minutes.
Designed for durability
Large heavy-duty revolving frame guards and swivel guard help protect vital components from damage and debris build-up.
Ease of maintenance and serviceability
Provide a convenient and more secure work area in front of the engine. A new step provides easier access for filling the AdBlue/DEF tank.
Specifications for PC240LC-11
Engine
Model Komatsu SAA6D107E-3* Type Water-cooled, 4-cycle, direct injection Aspiration Turbocharged, aftercooled, cooled EGR Number of cylinders 6 Bore 4.21 in Stroke 4.88 in Piston displacement 408 in³ Horsepower SAE J1995 : Gross 189 HP ISO 9249/SAE J1349 : Net 177 HP Rated rpm 2,000 rpm Fan drive type Mechanical Governor All-speed control, electronic *EPA Tier 4 Final emissions certified
Hydraulics
Type: HydrauMind (Hydraulic Mechanical Intelligence New Design) system, closed-center system with load sensing valves and pressure compensated valves
Number of selectable working modes 6
Main pump: Type Variable displacement piston type Pumps for Boom, arm, bucket, swing, and travel circuits Maximum flow 125.5 US gpm Supply for control circuit Self-reducing valve Hydraulic motors: Travel 2 x axial piston motor with parking brake Swing 1 x axial piston motor with swing holding brake Relief valve setting: Implement circuits 5,400 psi Travel circuit 5,400 psi Swing circuit 4,190 psi Pilot circuit 470 psi Hydraulic cylinders: Number of cylinders Bore x Stroke x Rod Diameter Boom / 2 5.3 x 52.6 x 3.5 in Arm / 1 5.5 x 64.4 x 3.9 in Bucket / 1 5.1 x 40.2 x 3.5 in Drives and Brakes Steering control Two levers with pedals Drive method Hydrostatic Maximum drawbar pull 45,349 lbs. Gradeability 70%, 35° Maximum travel speed: (Auto-Shift) High 3.4 mph Mid 2.5 mph Low 1.9 mph Service brake Hydraulic lock Parking brake Mechanical disc brake Swing System Drive method Hydrostatic Swing reduction Planetary gear Swing circle lubrication Grease-bathed Service brake Hydraulic lock Holding brake/Swing lock Mechanical disc brake Swing speed 11.7 rpm Swing torque 58,334 ft.-lbs. Undercarriage Center frame X-frame Track frame Box-section Seal of track Sealed track Track adjuster Hydraulic Number of shoes 51 each side Number of carrier rollers 2 each side Number of track rollers 10 each side Sound Performance Exterior ISO 6395 103 dB(A) Operator ISO 6396 70 dB(A) Coolant & Lubricant Capacity (Refilling) Fuel tank 105.7 US gal Coolant 10 US gal Engine 6.1 US gal Final drive, each side 1.3 US gal Swing drive 1.9 US gal Hydraulic tank 34.9 US gal Hydraulic system 64.4 US gal DEF tank 10.4 US gal Operating Weight (Approximate) Operating weight, including 19 ft. 2 in one-piece boom, 10 ft. 0 in arm, SAE heaped 1.85 yd³ bucket, rated capacity of lubricants, coolant, full fuel tank, operator, and standard equipment. Triple-Grouser Shoes 28 in Operating Weight 55,763 lbs. Ground Pressure 6.68 psi Triple-Grouser Shoes 31.5' in Operating Weight: 56,380 lbs. Ground Pressure 5.91 psi Component Weights Arm including bucket cylinder and linkage: 10 ft. 0 in arm assembly 2,694 lbs. 10 ft. 0 in HD arm assembly 2,906 lbs. 11 ft. 6 in arm assembly 3,179 lbs. One piece boom including arm cylinder: 20 ft. 2 in boom assembly 4,892 lbs. 20 ft. 2 in HD boom assembly 5,126 lbs. Boom cylinders x 2 463 lbs. Counterweight 10,296 lbs. 1.85 yd³ bucket - 48 in width 2,400 lbs.
