Supervac Vortex Parking Area Sweeper

93c294ee
3ad52bc6

Schwarze Industries proudly presents the SuperVac Gale Force, a sweeping marvel that's more than just a machine. It's a testament to our unwavering commitment to quality, performance, and innovation.

This cutting-edge street sweeper comes mounted on a robust gas-powered cab-over chassis, promising unparalleled durability and reliability. A fully welded hopper is at its heart, available in either stainless or mild steel. The hopper doesn't just resist corrosion and abrasion—it scoffs at them! Its increased structural strength reflects Schwarze's dedication to long-lasting and high-performing products.

But the SuperVac Gale Force isn't just about toughness. It's equipped with all LED safety lighting, ensuring your operations are safe even under low visibility conditions. The external stainless steel inspection door latches are designed for easy access, while the hydraulic lift dump door makes emptying the hopper a breeze. Not to mention, the large hopper clean-out door simplifies maintenance like never before.

Now, let's talk about performance. The SuperVac Gale Force is powered by a 28-HP gasoline auxiliary engine, guaranteeing efficient and superior sweeping. But the show's true star is the industry-leading Schwarze WhisperWheel Fan Technology. This innovative feature ensures maximum suction power without the noise, making the Gale Force the quietest yet most powerful sweeper on the market. We offer optional dual gutter brooms for those seeking even more sweeping prowess, enhancing your cleaning reach and capabilities.

The Schwarze SuperVac Gale Force isn't just a product—it's a promise. A promise of superior quality, unmatched performance, and relentless innovation. Trust Schwarze Industries to keep your streets clean and your operations smooth. Experience the Gale Force today. Your city deserves nothing less.

Specifications

CHASSIS

  • Make: Isuzu NPR
  • Length: Gas - 218 in (5,537 mm) to Diesel - 238 in (6,045 mm)
  • Width: 85 in (2,169 mm)
  • Steering: Left side
  • Fuel: Diesel; Gas
  • Lighting: Chassis light standard; Barlight, strobe lights & arrow board optional
  • Accessories: Backup camera; Heavy duty bumper, seat covers & spare tire optional

DEBRIS PICKUP SYSTEM

  • Technology: Regenerative Air
  • Type: Sweeping head with debris-moving blast & suction
  • Width no brooms: 82 in (2,083 mm)
  • Width one broom: 96 in (2,438 mm)
  • Max. width: 112 in (2,845 mm)
  • Surface area: 1,886 sq in (12,168 sq cm)
  • Construction: 10 gauge abrasion-resistant steel with rubber seal flaps
  • Skids/Dirt shoes: Tungsten carbide skids
  • Opp. Direction: Forward & reverse
  • Suspension Head/Main Broom: 4 adjustable springs
  • Control: Hydraulic raise & lower
  • Hopper conn.: Two 10 in (254 mm) hoses; Wire-reinforced molded rubber hoses optional
  • Cleaning assist: Manual clean
  • Optional conf.: 6 catch basin cleaning hand hose; Front mounted FOD magnet bar

STANDARD SWEEPER ENGINE

  • Make: B&G Vanguard Big Block
  • Type: 2 cylinder air cooled gasoline
  • Displacement: 54.68 cu in (0.9 L)
  • Horsepower: 25 hp (19 kw) @ 3600 rpm
  • Torque: 52.2 ft lb (70.8 Nm) @ 2200 rpm
  • Air cleaner: Dual Element
  • Oil filter: Full-flow spin-on
  • Stroke: 3.07 in (78 mm)
  • Bore: 3.37 in (86 mm)
  • Safety shutdown: Automatic
  • Throttle control: Electronic
  • Protection: Shielded; Shroud with sound deadening material optional
  • Optional engine: Kohler; Honda

CONTROL SYSTEM

  • Controls: Heavy duty rocker switches; On swivel stand; Throttle control
  • Instrumentation: Tachometer; Hourmeter; Temperature; Oil pressure
  • Voltage: 12 volt
  • Alternator: 145 amp
  • Circuit breakers: Resettable type

HYDRAULIC SYSTEM

  • Type: Fixed displacement gear
  • Pump capacity: 8 gpm (30 lpm) @ 1800 rpm (30 lpm) per section for 16 gpm total
  • Drive: Belt
  • Max.pressure: 2250 psi (156 bar)
  • Reservoir: 8.5 gallon (32.17L)
  • Filter: 10 micron; spin on
  • Suction strainer: 100 mesh
  • Protection: Pressure relief valve
  • Controls: Electro-hydraulic

FAN SYSTEM

  • Type: Closed-face radial Whisperwheel
  • Drive: Direct via 5 groove; banded power v-belt
  • Construction: Hardox steel
  • Balance: Less than 1.5 grams on 2 sides
  • Diameter: 24 in (610 mm)
  • Housing lining: Bolt-in corded rubber
  • Mounting: 2 sealed bearings
  • Vacuum enh.: Fan leaf bleeder door for heavy/light material with in-cab indicator

BROOMS

  • Type: Vertical steel digger
  • Location: Left forward of pickup head
  • Diameter: 26 in (660 mm)
  • Drive: Hydraulic
  • Suspension: Torque-sensing spring
  • Wear adj.: Automatic
  • Down Pressure: Manual
  • Speed: Variable; non-reversing
  • Segments: 2, disposable
  • Tilt angle adj.: Manual
  • Damage control: Object avoiding lateral flexibility; Water draining
  • Visibility: LED work light; Parabolic mirror optional; Up to 3 additional cameras optional

DEBRIS HOPPER

  • Vol. capacity: 4.5 cu yd (3.4 cu m)
  • Construction: Stainless; Carbon optional
  • Dump angle: 88 degrees
  • Floor angle: 0 degrees
  • Lifting: Twin hydraulic cylinders
  • Dump door: Hydraulic open, close, lock at rear
  • Inspection: 1 door on each side of the hopper; full load alarm optional
  • Dump height: 77 in (1,956 mm)
  • Debris screens: Dropdown
  • Safety: Dual body props; rearview camera; backup alarm; high visibility package
  • Hopper options: Dump assist shaker; Hopper drain
  • Storage: Two lockable storage areas at the rear of sweeper; shovel storage; rear trash bag rack optional

DUST CONTROL SYSTEM

  • Type: Electric diaphragm pump with run-dry capable
  • Capacity: 93 gal (352 L) to 159 gal (601.8 L)
  • Tank constr.: Polyethylene
  • Filter: 50 mesh; Cleanable
  • Fill diameter: 3 in (76.2 mm)
  • Fill hose: Optional
  • Controls: Electric; in-cab
  • Nozzles: 2 at each side broom; 1 at sweeping head; 2 at hopper intake; across front bumper optional; inside hopper optional
  • Water level Ind.: At water tank
  • Water press.: 70 PSI

BACKUP HYDRAULIC SYSTEM

  • Type: N/A
  • Function: N/A

MISC.

  • Paint: One coat of sealer/primer and two coats of Dupont Imron Elite polyurethane in standard white color; Special colors or graphics wrap optional
