SY35U EXCAVATOR
SANY's SY35U was built to be an all-purpose machine, balancing power with smoothness and fuel efficiency with speed. This mini excavator offers multiple work modes to tackle a variety of different jobs, and features a fully enclosed cab with in-cab monitor for quick, intuitive and comfortable operation. Built on a durable frame to handle tough terrain and working conditions, this track-driven excavator is ready to handle all your earth-moving and road-building projects.
Limited tail swing radius and independent boom swing allow operation in extremely confined spaces The independently developed intelligent control system matches pump output to available engine power for greater hydraulic system efficiency and lower fuel consumption
WHY SANY SWING BOOM EXCAVATORS?
SANY's swing boom excavators are the champions of confined spaces. Offered in a variety of machine configurations, these mini and small excavators fit various applications like landscaping, utilities, general construction, sewer and land management. All models feature standard auxiliary lines to run powered attachments. The SY35U through the SY80U boast spacious, comfortable, climate-controlled cabs to keep you cool in the summer and warm in the winter.
THE INVESTMENT THAT KEEPS ON RETURNING
Simply put, these machines are the achievers of any jobsite. They deliver all day long and they come loaded with standard features and the industry's strongest standard warranty. They're reliable and durable to take you the extra mile.
SAFETY
At SANY America, our equipment is designed with safety and service in mind. Before any machine hits the ground, it receives a pre-delivery inspection to ensure proper and safe operation. Standard safety features on all models include, but are not limited to, high visibility, intuitive control layouts, ergonomic joysticks and switches, adjustable and comfortable operator seats, camera systems and LED work light packages.
SERVICE
When we say that SANY machines are built to endure, we’re really talking about service. SANY equipment is intentionally designed to be easily and efficiently serviced, with features such as wide compartment doors and ground level access where possible to make maintenance more efficient. Because ease of service means back in service.
WE’VE GOT YOUR BACK
To provide peace of mind and ensure maximum uptime, SANY backs all its equipment with robust standard warranties. That’s our commitment to keeping your fleet running at peak performance. Our network of local dealers will partner with you for routine maintenance and be there for warranty repairs. You can trust SANY to keep you moving, year-round.
SPECIFICATIONS & COMPAREADD A MODEL TO COMPARE
MODEL SY35U
OVERALL DIMENSIONS
HIDE Boom Length 2540 mm 8' 4 Stick (Arm) Length 1400 mm 4' 7 Transport Length 4915 mm 16' 2 Transport Width 1720 mm 5' 8 Transport Height 2515 mm 8' 3 Upper Structure Width 1550 mm 5' 1 Cab Height Blade Height 350 mm 14 Track Width (standard shoe) 300 mm 12 Track Gauge 1420 mm 4' 8 Ground Clearance (minimum) 295 mm 12 Tail Swing Radius 860 mm 2' 10 Track Length on Ground 1670 mm 5' 6 Track Length 2155 mm 7' 1
TECHNICAL SPECIFICATIONS
HIDE Operating Weight 3855 kg 8,499 lb Ground Pressure 32.0 kPa 4.6 psi
Engine Yanmar 3TNV88F
Displacement 1.6 L 97.6 in3 Gross Power 18.2 kW 24.4 HP
Hydraulics Load Sensing with Pilot Control
Main Hydraulic Pump Axial Piston - Variable Displacement
Operating Flow (maximum) 88.0 L/min 23.2 gal/min Operating Pressure (maximum) 24.5 MPa 3553 psi Power Boost Pressure (maximum)
Travel Motor Axial Piston with Park Brake
Travel Pressure (maximum) 24.5 MPa 3553 psi Travel Speeds (maximum) 2.4 / 4.4 km/hr 1.5 / 2.7 mph Travel Effort (maximum) 36.8 kN 8,273 lbf Grade Capability 35°
Swing Motor Axial Piston with Swing Brake
Swing Pressure (maximum) 20.6 MPa 2988 psi Swing Speed (maximum) 9 rpm
Undercarriage (standard) Belted Rubber Track
Track Shoe Width (standard) 300 mm 12 Track Rollers (per side) 4 Carrier Rollers (per side) 1
WORKING RANGE
HIDE Boom Length 2540 mm 8' 4 Stick (Arm) Length 1400 mm 4' 7 Maximum Digging Height 4855 mm 15' 11 Maximum Dumping Height 3460 mm 11' 4 Maximum Digging Depth 3105 mm 10' 2 Maximum Vertical Wall Digging Depth 2700 mm 8' 10 Maximum Reach at Ground Level 5465 mm17' 11 Minimum Swing Radius 2475 mm 8' 1
